Net Relay Ext
Addon Sensor Board for IoT Platform
Net Relay Ext is an addon card for Net Relay. It has 8 GPIO channel, 8 ADC channels, 1 K-type thermocouple input channel, 1 DAC output channel, 1 serial port and onboard hummidity, pressure, temperature sensor and internal eeprom.
Electrical
Mechanical
Environment
| Net Relay Connection | 10pin FPC |
|---|
| Dimensions | 10 x 6.5 x 1.5cm |
|---|
| Operating Temp | -10°C ~ 40°C |
|---|---|
| Rel. humidity (non-condensing) | 10%~90% |
