Datalogger
Electrical
Mechanical
Environment
PC Reqs.
| Power | 12/24VDC - 0.5A |
|---|---|
| Network (Wireless) | 802.11b/g/n WPA1/2 |
| USB | 2.0 Type B (Serial Port) |
| Antenna | Internal (in front panel) |
| Dimensions | 7.0 x 13.5 x 5.1cm |
|---|---|
| Mounting | None |
| Material | ABS |
| Operating Temp | -10°C ~ 40°C |
|---|---|
| Rel. humidity (non-condensing) | 10%~90% |
| OS | Windows 8 or higher |
|---|---|
| Processor | Intel Pentium 4 equiv. or higher |
| RAM | Minimum 2 GB |
| Free Disk Space | Minimum 8 GB |
| Internet Connection | Static or dynamic |
Datalogger
Datalogger is an industrial 24V digital data acquision device. It can be placed with minimal power connection to collect data from machines.
